KEEP YOUR POOL AT PERFECT TEMPERATURE ALL SEASON LONG
- ICEBREAKER® heat and cool – extends swimming season longer than any other heat pump on the market
- Continues to heat at freezing temperatures to minimize heat loss
- Cools your pool to a refreshing temperature
- Patented high performance ThermoLink® titanium heat exchanger maximizes flow efficiency
- Weather protected microprocessor control with full text LCD display is easy to use and compatible with most external controllers
- Impact resistant, rust and fade proof cabinet with built-in drain pan provides condensate management
- Quieter than conventional heat pumps
Now you can control your heat pump right through your smartphone. Adjust your temperature setting in the PoolSync app.
*Additional purchase of PoolSync WiFi Controller required
AHRI’s globally recognized and industry respected heat pump pool heaters certification program provides outstanding value to equipment and component manufacturers, customers, and government regulators. AHRI Certified® products are subject to rigorous and continuous testing by a third-party laboratory under contract to AHRI. Only products certified by AHRI are listed in AHRI’s Directory of Certified Product Performance, a real-time database at web page. More information can be found online on the heat pump pool heaters Certification Program (web page), and the heat pump pool heaters contractors (web page).
California residents – Click here for Proposition 65 warning
Brochures & Manuals
Specs 60Hz
| 60Hz | T135R |
|---|---|
| BTUs (water temp/ambient air/relative humidity) |
|
| 80/80/80 | 123,000 |
| 80/80/63 | 118,000 |
| 80/50/63 | 78,000 |
| Coefficient of Performance (water temp/ambient air/relative humidity) |
|
| 80/80/80 | 5.5 |
| 80/80/63 | 5.2 |
| 80/50/63 | 4.0 |
| Refrigerant | R410A |
| Heat Exchanger | ThermoLink® |
| Electrical | |
| kW Input | 6.7 |
| Voltage/Hz/Phase | 208-230/60/1 |
| Minimum Circuit Ampacity | 43.3 |
| Maximum Fuse Size | 60 |
| Water Flow | |
| Minimum/Maximum (gpm) | 30/70 |
| * A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135. | |
| Physical | |
| Weight (lbs) | 264 |
| Length x Width x Height (in) | 34″ x 34″x 39″ |
| Shipping | |
| Weight (lbs) | 304 |
| Length x Width x Height (in) | 37″ x 36″x 45″ |
| Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity Specifications subject to change |
|
Specs 50Hz
| 50 Hz | T135R |
|---|---|
| Efficiency | |
| kW Output | 30.0 |
| BTU Output | 102,000 |
| Coefficient of Performance | 6.8 |
| kW Input | 4.4 |
| Electrical | |
| Heat or Heat & Cool | H & C |
| Voltage/Hz/Phase 50Hz: H-220-240/50/1 D-380-415/50/3 |
D |
| Maximum Fuse Size | D – 25 |
| Minimum Circuit Ampacity | D – 17.2 |
| Refrigerant | R410A |
| Heat Exchanger | ThermoLink® |
| Water Flow | |
| Min./Max. Water Flow (m3/h) | 6.8/15.9 |
| Min./Max. Water Flow (gpm) | 30/70 |
| Physical | |
| Weight (kg) | 122 |
| Weight (lb) | 267 |
| Length x Width x Height (cm) | 87 x 87 x 100 |
| Length x Width x Height (in) | |
| Weight (kg) | 140 |
| Weight (lbs) | 307 |
| Length x Width x Height (cm) | 94 x 92 x 115 |
| Length x Width x Height (in) | 38″ x 36″ x 45″ |
